Deep Dive into an ORM:

The Entity Framework Core Query Pipeline

whoami

  • Shay Rojansky
  • Engineer at Microsoft, part of the Entity Framework/Data team
  • Lead dev of Npgsql
    • .NET driver for PostgreSQL
    • PG provider for Entity Framework Core
  • Linux guy
  • Based in Berlin

What’s this about?

  • Not a talk about low-level intrinsics/GC/JIT/assembly
  • Not a talk about EF Core 3.0 new features
  • Deep dive into how an ORM works
  • Lots of architecture (and performance!)

Reminder about ORMs

  • Without ORMs, devs have to:
    • Write SQL (without compile-time verification)
    • Serialize/deserialize results (materialization)

ORMs and .NET

  • C# is unique because it has LINQ
  • ORMs in other languages define their own operator functions
  • However: LINQ can express far more than what is translatable to SQL

Entity Framework Core

  • We had LINQ to SQL, EF6…
  • EF Core 3.0 just released
    • Query pipeline got rewritten
  • Unique: not just for relational databases (SQL)

Let’s Talk about Expression Trees!

Expression Trees

Func<int, bool> comparer = num => num < 5;
Expression<Func<int, bool>> comparerExpression
   = num => num < 5;
Func compiled = comparerExpression.Compile();
var numParam = Expression.Parameter(typeof(int), "num");

Expression<Func<int, bool>> comparerExpression2 =
    Expression.Lambda<Func<int, bool>>(
        Expression.LessThan(
            numParam,
            Expression.Constant(5)),
        numParam);

var compiled2 = comparerExpression2.Compile();

Expression Trees - For Perf

  • Great solution for code generation
  • Generate specific, tailored lambdas based on config/user input
  • Compiled delegates run (almost) as fast as if they were written by hand

Expression Trees - Alternatives

Roslyn - high-level source representation

T4 - source representation with templates

Expression trees

Reflection.Emit - low-level IL

IQueryable

  • Up to now we compiled expression trees to IL for execution
  • IQueryable allows building providers which execute trees in other ways
  • ORMs: take the expression tree, convert it to SQL, send it to DB and materialize the results

Let’s Get Translating!

Null Semantics

Let’s translate this:

employees.Where(c => c.FirstName == c.LastName)
To this, right?
SELECT ... FROM Employees WHERE FirstName = LastName

Could be wrong, SQL has three-valued logic

In SQL, FirstName = NULL is never true… (and it ain’t false either :))

Null Semantics 2

Try to mimic C# behavior (best-effort only!)

WHERE FirstName = LastName OR
  (FirstName IS NULL AND LastName IS NULL)

If one of the columns is non-nullable in the database schema, we can optimize

Counter-example: case-sensitivity

Subqueries

Let’s get complicated:

employees.Where(e => e.Tasks.Count == 2)
SELECT ...
FROM Employees AS e
WHERE (
    SELECT COUNT(*)
    FROM Tasks AS t
    WHERE t.EmployeeId = e.Id
) = 2;

Instance Equality

What about this?

employees.Where(e => e == e.Boss)
We need to compare keys:
WHERE e.Id = Boss.Id
The same happens if instead of a Boss we have a subquery:
employees.Where(e => e.Tasks.First() == x)

WHERE (SELECT ... FROM Tasks ...).Id1 = x.Id1

More Instance Equality

Now, what happens if something has a composite key?

WHERE Id1 = Boss.Id1 AND Id2 = Boss.Id2
And with a subquery?
employees.Where(e => e.Tasks.First() == x)
WHERE (SELECT ...).Id1 = x.Id1 AND (SELECT ...).Id2 = x.Id2

Double evaluation… Better not do this!

Related Instances

In C#, “related instances” are just there in memory.

With DB, we need to fetch only what's needed:
employees.Include(b => b.Tasks)
SELECT ...
FROM Employees AS e
LEFT JOIN Tasks AS t ON e.Id = t.EmployeeId
ORDER BY e.Id, t.Id
  • Previous versions of EF Core translated this with multiple queries
    • Multiple roundtrips vs. “cartesian explosion”
    • Transactionality

Untranslatability

What to do about this?

employees.Where(e => SomeFunc(e))

Previous versions: translate to server if we can, otherwise evaluate on client

  • Can bring lots of data to client
  • Adding a new translation can break behavior

EF Core 3 throws, except for top-most projection

Lessons Learned

  • There are many, many mismatches between C# LINQ and SQL
  • ORMs need to make decisions about how to translate
  • We need to do many things to expression trees before they can be converted

Zoom out: How to do all this?

Query Pipeline: Inputs and Outputs

  • Input: LINQ expression tree (from IQueryable)
  • Outputs (for relational)?
    • SQL
    • Shaper / materializer, to read results (DbDataReader)
  • We are building a compiler!

Architecture

  • The query engine is architected as a pipeline of visitors
  • Each visitor traverses the expression tree, responsible for doing one thing

Example Visitor

  • For example, the instance equality visitor:
    • Traverses the entire tree
    • Identifies equality expression over instances
    • Replaces with equality over their keys

Minimal Visitor Exercise

Exercise: optimize an expression tree, eliminating needless null checks on non-nullable database columns:

// INPUT:
customers.Where(c => c.Age > 18 && c.Name != null)

// OUTPUT:
customers.Where(c => c.Age > 18)
class MyVisitor1 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.NotEqual)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value == null &&
                !IsNullable(b.Left))
            {
                return Expression.Constant(true);
            }
            // TODO: Sides may be flipped!
        }

        return visited;
    }
}
customers.Where(c => c.Age > 18 && true)
class MyVisitor2 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.AndAlso)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value is bool boolValue &&
                boolValue)
            {
                return b.Left;
            }
            // TODO: Same for other side!
        }
        // TODO: Also take care of OrElse!

        return visited;
    }
}
customers.Where(c => c.Age > 18)

Recap

From this:

customers.Where(c => c.Age > 18 && c.Name != null)
To this:
customers.Where(c => c.Age > 18 && true)
To this:
customers.Where(c => c.Age > 18)

EF Core Preprocessor

public virtual Expression Process(Expression query)
{
    query = new EnumerableToQueryableMethodConvertingExpressionVisitor().Visit(query);
    query = new QueryMetadataExtractingExpressionVisitor(_queryCompilationContext).Visit(query);
    query = new AllAnyToContainsRewritingExpressionVisitor().Visit(query);
    query = new GroupJoinFlatteningExpressionVisitor().Visit(query);
    query = new NullCheckRemovingExpressionVisitor().Visit(query);
    query = new EntityEqualityRewritingExpressionVisitor(_queryCompilationContext).Rewrite(query);
    query = new SubqueryMemberPushdownExpressionVisitor().Visit(query);
    query = new NavigationExpandingExpressionVisitor(...).Expand(query);
    query = new FunctionPreprocessingExpressionVisitor().Visit(query);
    new EnumerableVerifyingExpressionVisitor().Visit(query);

    return query;
}

SQL Translation

  • We’ve been talking about LINQ methods, but… at some point we want a model of an SQL query.
  • Instead of CLR types, methods and members, we want tables and columns.
customers
   .Where(c => c.Name == "Joe")
   .OrderBy(c => c.Age)
   .Take(5)
   .Select(c => new { c.Name, c.Age });
SELECT Name, Age FROM Customers
WHERE Age > 18
ORDER BY Age
LIMIT 10

SQL Translation 2

Still expressions, but now custom SQL ones!

customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

// Becomes:
WHERE c.ID IN (1, 2, 3) // This is an SqlInExpression

Expression trees can have custom expression types

Non-relational providers will do something completely different

Provider and User Translations

customers.Where(c => c.Name.Length > 5)

// Becomes:
WHERE LEN(c.Name) > 5    // On SqlServer
WHERE LENGTH(c.Name) > 5 // On PostgreSQL

Users can define functions which render into arbitrary SQL expressions

End of the Line

  • Some more postprocessing after SQL translation
  • QuerySqlGenerator is just another visitor, outputs an SQL string
  • Another visitor code-generates the shaper

(…with… expression trees…)

Query Pipeline Overview

Query Pipeline

Let’s talk about Perffffff

Parameterized Queries

var posts1 = ctx.Posts.Where(p => p.Title.Contains("dotnetos"));

var title = "dotnetos";  // Read from somewhere
var posts2 = ctx.Posts.Where(p => p.Title.Contains(title));
SELECT ... FROM Posts WHERE STRPOS('dotnetos') > 0;
SELECT ... FROM Posts WHERE STRPOS(@p) > 0;
  • Can leverage cached plans and prepared queries
  • Closure variables are your way of asking for parameterization

Compilation is Slow

  • No way we run all these visitors each time
  • The answer is always, always… caching.
  • Input: expression tree. Outputs: SQL+shaper.

Structural Comparison

We can just do recursive structural comparison:

var posts = ctx.Posts.Where(p => p.Title.Contains("dotnetos"));

Parameter Extraction

var title = "dotnetos";  // Read from somewhere
var posts2 = ctx.Posts.Where(p => p.Title.Contains(title));
  • Before checking the cache, identify parameter references (to closure variables)
  • Extract them out and replace them with placeholders, “punching holes in the tree”

Zoom out Again

Full pipeline

Cool! However, for each query, we still do:
  • Parameter extraction
  • Cache key hashcode calculation
  • Structural comparison with trees in the query cache

Compiled Queries

using (var ctx = new MyContext())
{
    var id = 8;
    var posts = ctx.Posts.Single(p => p.Id == id);
}

// Create an explicitly compiled query
private static Func<MyContext, int, Post> _postById
    = EF.CompileQuery((MyContext ctx, int id) =>
        ctx.Posts.Single(p => p.Id == id));

// Use the compiled query by invoking it
using (var ctx = new MyContext())
{
   var post = _postById(ctx, 8);
}

Not always so easy

Remember our InExpression from before?

customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

WHERE c.Id IN (1, 2, 3)
How do we parameterize this?
var customerIds = new[] { 1, 2, 3 };
customers.Where(c => customerIds.Contains(c.Id));

Solution :(

Expand to constant at execution time:

var values = new[] { 1, 2, 3 };
ctx.Posts.Where(p => values.Contains(p.Foo));

WHERE p.Foo IN (1, 2, 3)
  • Pollutes database query cache
  • PostgreSQL has WHERE p.Foo = ANY (@p)

Closing Words

  • Writing an ORM is… complex :)
  • Being aware of what happens under the hood is always important.
  • Check the SQL being generated!

Actual Heroes

Smit Patel

(new query pipeline architect)

Maurycy Markowski

(big query guy and also a Polish guy!)

And of course … the rest of the EF team
