Deep Dive into an ORM: The Entity Framework Core Query Pipeline

EF Title Logo

Deep Dive into an ORM:

The Entity Framework Core Query Pipeline

whoami

Shay Rojansky
Engineer at Microsoft, part of the Entity Framework/Data team
Lead dev of Npgsql
- .NET driver for PostgreSQL
- PG provider for Entity Framework Core
Linux guy
Based in Berlin

What’s this about?

Not a talk about low-level intrinsics/GC/JIT/assembly {.fragment}
Not a talk about EF Core 3.0 new features {.fragment}
Deep dive into how an ORM works {.fragment}
Lots of architecture (and performance!) {.fragment}

–

Reminder about ORMs

Without ORMs, devs have to:
- Write SQL (without compile-time verification)
- Serialize/deserialize results (materialization)

–

ORMs and .NET

C# is unique because it has LINQ
ORMs in other languages define their own operator functions {.fragment}
However: LINQ can express far more than what is translatable to SQL {.fragment}

–

Entity Framework Core

We had LINQ to SQL, EF6…
EF Core 3.0 just released {.fragment}
- Query pipeline got rewritten
Unique: not just for relational databases (SQL) {.fragment}

–

Let’s Talk about Expression Trees!

–

Expression Trees

Func<int, bool> comparer = num => num < 5;

Expression<Func<int, bool>> comparerExpression
   = num => num < 5;
Func<int, bool> compiled = comparerExpression.Compile();

var numParam = Expression.Parameter(typeof(int), "num");

Expression<Func<int, bool>> comparerExpression2 =
    Expression.Lambda<Func<int, bool>>(
        Expression.LessThan(
            numParam,
            Expression.Constant(5)),
        numParam);

var compiled2 = comparerExpression2.Compile();

–

Expression Trees - For Perf

Great solution for code generation
Generate specific, tailored lambdas based on config/user input
Compiled delegates run (almost) as fast as if they were written by hand

–

Expression Trees - Alternatives

Roslyn - high-level source representation {.fragment data-fragment-index=1}

T4 - source representation with templates {.fragment data-fragment-index=2}

Expression trees {.fragment data-fragment-index=4}

Reflection.Emit - low-level IL {.fragment data-fragment-index=3}

–

IQueryable

Up to now we compiled expression trees to IL for execution
IQueryable allows building providers which execute trees in other ways
ORMs: take the expression tree, convert it to SQL, send it to DB and materialize the results {.fragment}

Let’s Get Translating!

–

Null Semantics

Let’s translate this:

employees.Where(c => c.FirstName == c.LastName)

To this, right?

SELECT ... FROM Employees WHERE FirstName = LastName

Could be wrong, SQL has three-valued logic{style=color:red} {.fragment}

In SQL, FirstName = NULL is never true… (and it ain’t false either :))

–

Null Semantics 2

Try to mimic C# behavior (best-effort only!)

WHERE FirstName = LastName OR
  (FirstName IS NULL AND LastName IS NULL)

If one of the columns is non-nullable in the database schema, we can optimize {.fragment} Counter-example: case-sensitivity {.fragment} -- ## Subqueries Let's get complicated: ```csharp employees.Where(e => e.Tasks.Count == 2) ```

SELECT ...
FROM Employees AS e
WHERE (
    SELECT COUNT(*)
    FROM Tasks AS t
    WHERE t.EmployeeId = e.Id
) = 2;

-- ## Instance Equality What about this? ```c# employees.Where(e => e == e.Boss) ```

We need to compare keys:

WHERE e.Id = Boss.Id

The same happens if instead of a Boss we have a subquery:

employees.Where(e => e.Tasks.First() == x)

WHERE (SELECT ... FROM Tasks ...).Id1 = x.Id1

-- ## More Instance Equality Now, what happens if something has a composite key?

WHERE Id1 = Boss.Id1 AND Id2 = Boss.Id2

And with a subquery?

employees.Where(e => e.Tasks.First() == x)

WHERE (SELECT ...).Id1 = x.Id1 AND (SELECT ...).Id2 = x.Id2

**Double evaluation... Better not do this!**{style=color:red} -- ## Related Instances In C#, "related instances" are just there in memory.

With DB, we need to fetch only what's needed:

employees.Include(b => b.Tasks)

SELECT ...
FROM Employees AS e
LEFT JOIN Tasks AS t ON e.Id = t.EmployeeId
ORDER BY e.Id, t.Id

* Previous versions of EF Core translated this with multiple queries {.fragment} * Multiple roundtrips vs. "cartesian explosion" * Transactionality -- ## Untranslatability What to do about this? ```c# employees.Where(e => SomeFunc(e)) ``` Previous versions: translate to server if we can, otherwise evaluate on client {.fragment} * Can bring *lots* of data to client {.fragment} * Adding a new translation can break behavior {.fragment} EF Core 3 throws, except for top-most projection {.fragment style=color:red} -- ## Lessons Learned * There are many, many mismatches between C# LINQ and SQL * ORMs need to make decisions about how to translate {.fragment} * We need to do many things to expression trees before they can be converted {.fragment} --- ## Zoom out: How to do all this? -- ## Query Pipeline: Inputs and Outputs * Input: LINQ expression tree (from IQueryable) * Outputs (for relational)? * SQL {.fragment} * Shaper / materializer, to read results (DbDataReader) {.fragment} * We are building a compiler! {.fragment} -- ## Architecture * The query engine is architected as a pipeline of **visitors** {.fragment} * Each visitor traverses the expression tree, responsible for doing one thing {.fragment} -- ## Example Visitor * For example, the instance equality visitor: * Traverses the entire tree {.fragment} * Identifies equality expression over instances {.fragment} * Replaces with equality over their keys {.fragment} -- ## Minimal Visitor Exercise **Exercise**: optimize an expression tree, eliminating needless null checks on non-nullable database columns: ```csharp // INPUT: customers.Where(c => c.Age > 18 && c.Name != null) // OUTPUT: customers.Where(c => c.Age > 18) ``` --

class MyVisitor1 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.NotEqual)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value == null &&
                !IsNullable(b.Left))
            {
                return Expression.Constant(true);
            }
            // TODO: Sides may be flipped!
        }

        return visited;
    }
}

customers.Where(c => c.Age > 18 && true)

class MyVisitor2 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.AndAlso)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value is bool boolValue &&
                boolValue)
            {
                return b.Left;
            }
            // TODO: Same for other side!
        }
        // TODO: Also take care of OrElse!

        return visited;
    }
}

customers.Where(c => c.Age > 18)

-- ## Recap From this:

customers.Where(c => c.Age > 18 && c.Name != null)</pre>


To this:

customers.Where(c => c.Age > 18 && true)</pre>
</div>


To this:

customers.Where(c => c.Age > 18)</pre>
</div>

--

## EF Core Preprocessor

public virtual Expression Process(Expression query)
{
    query = new EnumerableToQueryableMethodConvertingExpressionVisitor().Visit(query);
    query = new QueryMetadataExtractingExpressionVisitor(_queryCompilationContext).Visit(query);
    query = new AllAnyToContainsRewritingExpressionVisitor().Visit(query);
    query = new GroupJoinFlatteningExpressionVisitor().Visit(query);
    query = new NullCheckRemovingExpressionVisitor().Visit(query);
    query = new EntityEqualityRewritingExpressionVisitor(_queryCompilationContext).Rewrite(query);
    query = new SubqueryMemberPushdownExpressionVisitor().Visit(query);
    query = new NavigationExpandingExpressionVisitor(...).Expand(query);
    query = new FunctionPreprocessingExpressionVisitor().Visit(query);
    new EnumerableVerifyingExpressionVisitor().Visit(query);

    return query;
}





The last one is a verifying visitor, no meaningful return value.


--

## SQL Translation

* We've been talking about LINQ methods, but... at some point we want a model of an SQL query.
* Instead of CLR types, methods and members, we want tables and columns.

--

customers
   .Where(c => c.Name == "Joe")
   .OrderBy(c => c.Age)
   .Take(5)
   .Select(c => new { c.Name, c.Age });







SELECT Name, Age FROM Customers
WHERE Age > 18
ORDER BY Age
LIMIT 10




SelectExpression has tables which have columns. All these are references.


--

## SQL Translation 2

Still expressions, but now custom SQL ones!

```c#
customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

// Becomes:
WHERE c.ID IN (1, 2, 3) // This is an SqlInExpression
```

Expression trees can have custom expression types {.fragment}

Non-relational providers will do something completely different {.fragment}

--

## Provider and User Translations

```csharp
customers.Where(c => c.Name.Length > 5)

// Becomes:
WHERE LEN(c.Name) > 5    // On SqlServer
WHERE LENGTH(c.Name) > 5 // On PostgreSQL
```

Users can define functions which render into arbitrary SQL expressions {.fragment}

--

## End of the Line

* Some more postprocessing after SQL translation
* QuerySqlGenerator is just another visitor, outputs an SQL string {.fragment}
* Another visitor code-generates the shaper {.fragment}

(...with... expression trees...) {.fragment}

--

## Query Pipeline Overview

![Query Pipeline](/talks/2019-10-08-dotnetos-efcore-query-internals/src/diagrams/pipeline.svg)

---

## Let's talk about Perffffff

--

## Parameterized Queries

```csharp
var posts1 = ctx.Posts.Where(p => p.Title.Contains("dotnetos"));

var title = "dotnetos";  // Read from somewhere
var posts2 = ctx.Posts.Where(p => p.Title.Contains(title));
```


SELECT ... FROM Posts WHERE STRPOS('dotnetos') > 0;
SELECT ... FROM Posts WHERE STRPOS(@p) > 0;


* Can leverage cached plans and prepared queries {.fragment}
* Closure variables are your way of asking for parameterization {.fragment}


Guy generating trees with constant every time


--

## Compilation is Slow

* No way we run all these visitors each time
* The answer is always, always... caching. {.fragment}
* **Input**: expression tree. **Outputs**: SQL+shaper. {.fragment}

--

## Structural Comparison

We can just do recursive structural comparison:

```csharp
var posts = ctx.Posts.Where(p => p.Title.Contains("dotnetos"));
```










* Literal/constant: "dotnetos" will get embedded in the SQL.
* Mention hash code computation, then equality. SLOW (but later compiled queries)


--

## Parameter Extraction

```csharp
var title = "dotnetos";  // Read from somewhere
var posts2 = ctx.Posts.Where(p => p.Title.Contains(title));
```

* Before checking the cache, identify parameter references (to closure variables)
* Extract them out and replace them with placeholders, "punching holes in the tree" {.fragment}

--

## Zoom out Again

![Full pipeline](/talks/2019-10-08-dotnetos-efcore-query-internals/src/diagrams/pipeline-full.svg)


Cool! However, for each query, we still do:

* Parameter extraction
* Cache key hashcode calculation
* Structural comparison with trees in the query cache



Pretty cool, compilation isn't perf sensitive and we can concentrate on a good clean design.

--

## Compiled Queries

```csharp
using (var ctx = new MyContext())
{
    var id = 8;
    var posts = ctx.Posts.Single(p => p.Id == id);
}
```


// Create an explicitly compiled query
private static Func<MyContext, int, Post> _postById
    = EF.CompileQuery((MyContext ctx, int id) =>
        ctx.Posts.Single(p => p.Id == id));

// Use the compiled query by invoking it
using (var ctx = new MyContext())
{
   var post = _postById(ctx, 8);
}


--

## Not always so easy

Remember our InExpression from before?

```csharp
customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

WHERE c.Id IN (1, 2, 3)
```


How do we parameterize this?

var customerIds = new[] { 1, 2, 3 };
customers.Where(c => customerIds.Contains(c.Id));



--

## Solution :(

Expand to constant **at execution time**:

```csharp
var values = new[] { 1, 2, 3 };
ctx.Posts.Where(p => values.Contains(p.Foo));

WHERE p.Foo IN (1, 2, 3)
```

* Pollutes database query cache
* PostgreSQL has `WHERE p.Foo = ANY (@p)` {.fragment}


Main point: provider extensibility, dependency injection


---

## Closing Words

* Writing an ORM is... complex :)
* Being aware of what happens under the hood is always important. {.fragment}
* Check the SQL being generated! {.fragment}

---

## Actual Heroes

**Smit Patel**

(new query pipeline architect)

**Maurycy Markowski**

(big query guy and also a Polish guy!)

**And of course ... the rest of the EF team**

---

## Thank you!

**Shay Rojansky**

Blog & Presentation: <http://roji.org>

Twitter: @shayrojansky
