Deep Dive into an ORM:

The Entity Framework Core Query Pipeline

whoami

Intro: ORMs and C#

ORMs: can’t live with them…

… can’t live without them

–

Why do we love ORMs?

Without ORMs, devs have to:

–

What’s this talk about?

Always be familiar with one layer underneath you! {.fragment}

–

Typical ORM code

Hibernate HQL:

String hql = "FROM Employee E WHERE E.id > 10 ORDER BY E.salary DESC";

Hibernate criteria API:

Criteria crit = session.createCriteria(Product.class);
Criterion priceLessThan = Restrictions.lt("price", 10.0);
Criterion mouse = Restrictions.ilike("description", "mouse", MatchMode.ANYWHERE);
LogicalExpression orExp = Restrictions.or(priceLessThan, mouse);
crit.add(orExp);
List results=crit.list();

–

ORMs in .NET

C# has LINQ (Language-Integrated Query)

var someArray = new[] { 1, 10, 2 };
var result = someArray
    .Where(i => i > 5)
    .OrderBy(i => i)
    .Take(2)
    .ToArray();

These are query operators, working in-memory.

–

IQueryable

C# allows us to use LINQ to express queries that don’t run in-memory

var employees = db.Employees
    .Where(e => e.Salary > 1000)
    .OrderBy(e => e.Salary)
    .Take(2)
    .ToArray();

–

IQueryable is great! But…

–

Entity Framework Core

Let’s Get Translating!

–

Null Semantics

Let’s translate this:

employees.Where(e => e.FirstName == e.LastName)
To this, right?
SELECT ... FROM Employees WHERE FirstName = LastName

Could be wrong, SQL has three-valued logic{style=color:red} {.fragment}

In SQL, FirstName = NULL is never true… (and it ain’t false either :))

–

Null Semantics 2

Try to mimic C# behavior (best-effort only!)

WHERE FirstName = LastName OR
  (FirstName IS NULL AND LastName IS NULL)
If one of the columns is non-nullable in the database schema, we can optimize {.fragment} Counter-example: case-sensitivity {.fragment} -- ## Subqueries Let's get complicated: ```csharp employees.Where(e => e.Tasks.Count == 2) ```
SELECT ...
FROM Employees AS e
WHERE (
    SELECT COUNT(*)
    FROM Tasks AS t
    WHERE t.EmployeeId = e.Id
) = 2;
-- ## Instance Equality What about this? ```c# employees.Where(e => e == e.Boss) ```
We need to compare keys:
WHERE e.Id = Boss.Id
The same happens if instead of a Boss we have a subquery:
employees.Where(e => e.Tasks.First() == x)

WHERE (SELECT ... FROM Tasks ...).Id1 = x.Id1
-- ## More Instance Equality Now, what happens if something has a composite key?
WHERE Id1 = Boss.Id1 AND Id2 = Boss.Id2
And with a subquery?
employees.Where(e => e.Tasks.First() == x)
WHERE (SELECT ...).Id1 = x.Id1 AND (SELECT ...).Id2 = x.Id2
**Double evaluation... Better not do this!**{style=color:red} -- ## Related Instances In C#, "related instances" are just there in memory.
With DB, we need to fetch only what's needed:
employees.Include(b => b.Tasks)
SELECT ...
FROM Employees AS e
LEFT JOIN Tasks AS t ON e.Id = t.EmployeeId
ORDER BY e.Id, t.Id
* Previous versions of EF Core translated this with multiple queries {.fragment} * Multiple roundtrips vs. "cartesian explosion" * Transactionality -- ## Lessons Learned * There are many, many mismatches between C# LINQ and SQL * ORMs need to make decisions about how to translate {.fragment} * We need to do many things to expression trees before they can be converted {.fragment} --- ## Expression Trees and Visitors -- ## Query Pipeline: Inputs and Outputs * Input: LINQ expression tree (from IQueryable) * Outputs (for relational)? * SQL {.fragment} * Shaper / materializer, to read results (DbDataReader) {.fragment} * We are building a compiler! {.fragment} -- ## Our Input: Expression Trees ```csharp Func<int, bool> comparer = num => num < 5; ```
Expression<Func<int, bool>> comparerExpression
   = num => num < 5;
Func<int, bool> compiled = comparerExpression.Compile();

var numParam = Expression.Parameter(typeof(int), "num");

Expression<Func<int, bool>> comparerExpression2 =
    Expression.Lambda<Func<int, bool>>(
        Expression.LessThan(
            numParam,
            Expression.Constant(5)),
        numParam);

var compiled2 = comparerExpression2.Compile();
-- ## Expression Trees - For Perf * Great solution for code generation * Generate specific, tailored lambdas based on config/user input -- ## Visitors * The query engine is architected as a pipeline of **visitors** {.fragment} * Each visitor traverses the expression tree, responsible for doing one thing {.fragment} -- ## Example Visitor * For example, the instance equality visitor: * Traverses the entire tree {.fragment} * Identifies equality expression over instances {.fragment} * Replaces with equality over their keys {.fragment} -- ## Minimal Visitor Exercise **Exercise**: optimize an expression tree, eliminating needless null checks on non-nullable database columns: ```csharp // INPUT: customers.Where(c => c.Age > 18 && c.Name != null) // OUTPUT: customers.Where(c => c.Age > 18) ``` --
class MyVisitor1 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.NotEqual)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value == null &&
                !IsNullable(b.Left))
            {
                return Expression.Constant(true);
            }
            // TODO: Sides may be flipped!
        }

        return visited;
    }
}

customers.Where(c => c.Age > 18 && true)
--
class MyVisitor2 : ExpressionVisitor
{
    protected override Expression VisitBinary(BinaryExpression b)
    {
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.AndAlso)
        {
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value is bool boolValue &&
                boolValue)
            {
                return b.Left;
            }
            // TODO: Same for other side!
        }
        // TODO: Also take care of OrElse!

        return visited;
    }
}

customers.Where(c => c.Age > 18)
-- ## Recap From this:
customers.Where(c => c.Age > 18 && c.Name != null)</pre>



To this:


customers.Where(c => c.Age > 18 && true)</pre>
</div>



To this:


customers.Where(c => c.Age > 18)</pre>
</div>

--

## EF Core Preprocessor


public virtual Expression Process(Expression query)
{
    query = new EnumerableToQueryableMethodConvertingExpressionVisitor().Visit(query);
    query = new QueryMetadataExtractingExpressionVisitor(_queryCompilationContext).Visit(query);
    query = new AllAnyToContainsRewritingExpressionVisitor().Visit(query);
    query = new GroupJoinFlatteningExpressionVisitor().Visit(query);
    query = new NullCheckRemovingExpressionVisitor().Visit(query);
    query = new EntityEqualityRewritingExpressionVisitor(_queryCompilationContext).Rewrite(query);
    query = new SubqueryMemberPushdownExpressionVisitor().Visit(query);
    query = new NavigationExpandingExpressionVisitor(...).Expand(query);
    query = new FunctionPreprocessingExpressionVisitor().Visit(query);
    new EnumerableVerifyingExpressionVisitor().Visit(query);

    return query;
}





--

## SQL Translation

* We've been talking about LINQ methods, but... at some point we want a model of an SQL query.
* Instead of CLR types, methods and members, we want tables and columns.

--


customers
   .Where(c => c.Name == "Joe")
   .OrderBy(c => c.Age)
   .Take(5)
   .Select(c => new { c.Name, c.Age });










SELECT Name, Age FROM Customers
WHERE Age > 18
ORDER BY Age
LIMIT 10







--

## SQL Translation 2

Still expressions, but now custom SQL ones!

```c#
customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

// Becomes:
WHERE c.ID IN (1, 2, 3) // This is an SqlInExpression
```

Expression trees can have custom expression types

--

## Provider and User Translations

```csharp
customers.Where(c => c.Name.Length > 5)

// Becomes:
WHERE LEN(c.Name) > 5    // On SqlServer
WHERE LENGTH(c.Name) > 5 // On PostgreSQL
```

Users can define functions which render into arbitrary SQL expressions {.fragment}

--

## End of the Line

* Some more postprocessing after SQL translation
* QuerySqlGenerator is just another visitor, outputs an SQL string
* Another visitor code-generates the shaper

--

## Query Pipeline Overview

![Query Pipeline](/talks/2019-11-30-codecamp-efcore-query-internals/src/diagrams/pipeline.svg)

---

## Let's talk about Performance

--

## Compilation is Slow

* No way we run all these visitors each time
* The answer is always, always... caching. {.fragment}

--

## Zoom out Again

![Full pipeline](/talks/2019-11-30-codecamp-efcore-query-internals/src/diagrams/pipeline-full.svg)



Cool! However, for each query, we still do:

* Some magic called parameter extraction
* Cache key hashcode calculation
* Structural comparison with trees in the query cache





--

## Compiled Queries

```csharp
using (var ctx = new MyContext())
{
    var id = 8;
    var posts = ctx.Posts.Single(p => p.Id == id);
}
```



// Create an explicitly compiled query
private static Func<MyContext, int, Post> _postById
    = EF.CompileQuery((MyContext ctx, int id) =>
        ctx.Posts.Single(p => p.Id == id));

// Use the compiled query by invoking it
using (var ctx = new MyContext())
{
   var post = _postById(ctx, 8);
}



---

## Closing Words

* Everybody loves ORMs
* ... and everybody hates ORMs {.fragment}
* Writing an ORM is... complex :) {.fragment}
* Being aware of what happens under the hood is always important. {.fragment}
* *Always* check the SQL being generated! {.fragment}

---

## Actual Heroes

**Smit Patel**

(new query pipeline architect)

**Maurycy Markowski**

(another big query guy)

**And of course ... the rest of the EF team**

---

## Thank you!

**Shay Rojansky**, <http://roji.org>, @shayrojansky
