Deep Dive into an ORM:

The Entity Framework Core Query Pipeline


  • Shay Rojansky
  • Engineer at Microsoft, part of the Entity Framework/Data team
  • Lead dev of Npgsql
    • .NET driver for PostgreSQL
    • PG provider for Entity Framework Core
  • Linux guy
  • Based in Berlin

Intro: ORMs and C#

ORMs: can’t live with them…

… can’t live without them

Why do we love ORMs?

Without ORMs, devs have to:

  • Write SQL (without compile-time verification)
  • Serialize/deserialize results (materialization)

What’s this talk about?

  • Not a talk about new EF Core features
  • Deep dive into how an ORM works
  • Lots of architecture (and performance!)

Always be familiar with one layer underneath you!

Typical ORM code

Hibernate HQL:

String hql = "FROM Employee E WHERE > 10 ORDER BY E.salary DESC";

Hibernate criteria API:

Criteria crit = session.createCriteria(Product.class);
Criterion priceLessThan ="price", 10.0);
Criterion mouse = Restrictions.ilike("description", "mouse", MatchMode.ANYWHERE);
LogicalExpression orExp = Restrictions.or(priceLessThan, mouse);
List results=crit.list();

ORMs in .NET

C# has LINQ (Language-Integrated Query)

var someArray = new[] { 1, 10, 2 };
var result = someArray
    .Where(i => i > 5)
    .OrderBy(i => i)

These are query operators, working in-memory.


C# allows us to use LINQ to express queries that don’t run in-memory

var employees = db.Employees
    .Where(e => e.Salary > 1000)
    .OrderBy(e => e.Salary)
  • Instead of evaluating, the compiler constructs an expression tree
  • The expression tree can be translated to SQL (or something else)

IQueryable is great! But…

  • Awesome: we can use regular C# language constructs to express SQL queries
  • Caveat1: we can express far more than what is translatable to SQL
  • Caveat2: there are many mismatches between C# and SQL
  • Caveat3: what can be expressed can’t always be translated efficiently

Entity Framework Core

  • We had LINQ to SQL, EF6…
  • EF Core 3.0 just released
    • Query pipeline got rewritten
  • Unique: not just for relational databases (SQL)

Let’s Get Translating!

Null Semantics

Let’s translate this:

employees.Where(e => e.FirstName == e.LastName)
To this, right?
SELECT ... FROM Employees WHERE FirstName = LastName

Could be wrong, SQL has three-valued logic

In SQL, FirstName = NULL is never true… (and it ain’t false either :))

Null Semantics 2

Try to mimic C# behavior (best-effort only!)

WHERE FirstName = LastName OR
  (FirstName IS NULL AND LastName IS NULL)

If one of the columns is non-nullable in the database schema, we can optimize

Counter-example: case-sensitivity


Let’s get complicated:

employees.Where(e => e.Tasks.Count == 2)
FROM Employees AS e
    FROM Tasks AS t
    WHERE t.EmployeeId = e.Id
) = 2;

Instance Equality

What about this?

employees.Where(e => e == e.Boss)
We need to compare keys:
WHERE e.Id = Boss.Id
The same happens if instead of a Boss we have a subquery:
employees.Where(e => e.Tasks.First() == x)

WHERE (SELECT ... FROM Tasks ...).Id1 = x.Id1

More Instance Equality

Now, what happens if something has a composite key?

WHERE Id1 = Boss.Id1 AND Id2 = Boss.Id2
And with a subquery?
employees.Where(e => e.Tasks.First() == x)
WHERE (SELECT ...).Id1 = x.Id1 AND (SELECT ...).Id2 = x.Id2

Double evaluation… Better not do this!

Related Instances

In C#, “related instances” are just there in memory.

With DB, we need to fetch only what's needed:
employees.Include(b => b.Tasks)
FROM Employees AS e
LEFT JOIN Tasks AS t ON e.Id = t.EmployeeId
ORDER BY e.Id, t.Id
  • Previous versions of EF Core translated this with multiple queries
    • Multiple roundtrips vs. “cartesian explosion”
    • Transactionality

Lessons Learned

  • There are many, many mismatches between C# LINQ and SQL
  • ORMs need to make decisions about how to translate
  • We need to do many things to expression trees before they can be converted

Expression Trees and Visitors

Query Pipeline: Inputs and Outputs

  • Input: LINQ expression tree (from IQueryable)
  • Outputs (for relational)?
    • SQL
    • Shaper / materializer, to read results (DbDataReader)
  • We are building a compiler!

Our Input: Expression Trees

Func<int, bool> comparer = num => num < 5;
Expression<Func<int, bool>> comparerExpression
   = num => num < 5;
Func<int, bool> compiled = comparerExpression.Compile();
var numParam = Expression.Parameter(typeof(int), "num");

Expression<Func<int, bool>> comparerExpression2 =
    Expression.Lambda<Func<int, bool>>(

var compiled2 = comparerExpression2.Compile();

Expression Trees - For Perf

  • Great solution for code generation
  • Generate specific, tailored lambdas based on config/user input


  • The query engine is architected as a pipeline of visitors
  • Each visitor traverses the expression tree, responsible for doing one thing

Example Visitor

  • For example, the instance equality visitor:
    • Traverses the entire tree
    • Identifies equality expression over instances
    • Replaces with equality over their keys

Minimal Visitor Exercise

Exercise: optimize an expression tree, eliminating needless null checks on non-nullable database columns:

customers.Where(c => c.Age > 18 && c.Name != null)

customers.Where(c => c.Age > 18)
class MyVisitor1 : ExpressionVisitor
    protected override Expression VisitBinary(BinaryExpression b)
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.NotEqual)
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value == null &&
                return Expression.Constant(true);
            // TODO: Sides may be flipped!

        return visited;
customers.Where(c => c.Age > 18 && true)
class MyVisitor2 : ExpressionVisitor
    protected override Expression VisitBinary(BinaryExpression b)
        var visited = (BinaryExpression)base.VisitBinary(b);

        if (b.NodeType == ExpressionType.AndAlso)
            if (b.Right is ConstantExpression rightConstant &&
                rightConstant.Value is bool boolValue &&
                return b.Left;
            // TODO: Same for other side!
        // TODO: Also take care of OrElse!

        return visited;
customers.Where(c => c.Age > 18)


From this:

customers.Where(c => c.Age > 18 && c.Name != null)
To this:
customers.Where(c => c.Age > 18 && true)
To this:
customers.Where(c => c.Age > 18)

EF Core Preprocessor

public virtual Expression Process(Expression query)
    query = new EnumerableToQueryableMethodConvertingExpressionVisitor().Visit(query);
    query = new QueryMetadataExtractingExpressionVisitor(_queryCompilationContext).Visit(query);
    query = new AllAnyToContainsRewritingExpressionVisitor().Visit(query);
    query = new GroupJoinFlatteningExpressionVisitor().Visit(query);
    query = new NullCheckRemovingExpressionVisitor().Visit(query);
    query = new EntityEqualityRewritingExpressionVisitor(_queryCompilationContext).Rewrite(query);
    query = new SubqueryMemberPushdownExpressionVisitor().Visit(query);
    query = new NavigationExpandingExpressionVisitor(...).Expand(query);
    query = new FunctionPreprocessingExpressionVisitor().Visit(query);
    new EnumerableVerifyingExpressionVisitor().Visit(query);

    return query;

SQL Translation

  • We’ve been talking about LINQ methods, but… at some point we want a model of an SQL query.
  • Instead of CLR types, methods and members, we want tables and columns.
   .Where(c => c.Name == "Joe")
   .OrderBy(c => c.Age)
   .Select(c => new { c.Name, c.Age });
SELECT Name, Age FROM Customers
WHERE Age > 18

SQL Translation 2

Still expressions, but now custom SQL ones!

customers.Where(c => new[] { 1, 2, 3 }.Contains(c.Id));

// Becomes:
WHERE c.ID IN (1, 2, 3) // This is an SqlInExpression

Expression trees can have custom expression types

Provider and User Translations

customers.Where(c => c.Name.Length > 5)

// Becomes:
WHERE LEN(c.Name) > 5    // On SqlServer
WHERE LENGTH(c.Name) > 5 // On PostgreSQL

Users can define functions which render into arbitrary SQL expressions

End of the Line

  • Some more postprocessing after SQL translation
  • QuerySqlGenerator is just another visitor, outputs an SQL string
  • Another visitor code-generates the shaper

Query Pipeline Overview

Query Pipeline

Let’s talk about Performance

Compilation is Slow

  • No way we run all these visitors each time
  • The answer is always, always… caching.

Zoom out Again

Full pipeline

Cool! However, for each query, we still do:
  • Some magic called parameter extraction
  • Cache key hashcode calculation
  • Structural comparison with trees in the query cache

Compiled Queries

using (var ctx = new MyContext())
    var id = 8;
    var posts = ctx.Posts.Single(p => p.Id == id);

// Create an explicitly compiled query
private static Func<MyContext, int, Post> _postById
    = EF.CompileQuery((MyContext ctx, int id) =>
        ctx.Posts.Single(p => p.Id == id));

// Use the compiled query by invoking it
using (var ctx = new MyContext())
   var post = _postById(ctx, 8);

Closing Words

  • Everybody loves ORMs
  • … and everybody hates ORMs
  • Writing an ORM is… complex :)
  • Being aware of what happens under the hood is always important.
  • Always check the SQL being generated!

Actual Heroes

Smit Patel

(new query pipeline architect)

Maurycy Markowski

(another big query guy)

And of course … the rest of the EF team

Thank you!

Shay Rojansky,, @shayrojansky
