Introducing Npgsql multiplexing: a high-performance database driver model

# Npgsql multiplexing

A high-performance database driver model

---

## whoami

* Shay Rojansky
* Engineer at Microsoft, part of the .NET data team
* Lead dev of Npgsql, PostgreSQL driver for .NET
* Linux guy
* Based in Berlin

Note:
Started with Slackware around 1995

---

## Who is Npgsql?

* .NET open-source driver for PostgreSQL
  * There's also an EF Core provider, but we'll focus on the low-level (ADO.NET).
* Bottom of the stack - beneath us is the .NET runtime
* Supposed to be a boring component!

---

## Performance

TechEmpower Round 20 (Feb 2021)

![TechEmpower round 20 composite scores](img/techempower.png "Logo Title Text 1")

<div class="fragment">... running on Linux with PostgreSQL</div>

Note:

* Already old (Feb 2021)
* Does not include newer improvements for .NET 6
* Many of these are experiments, not full-fledged web frameworks etc.
* The first Fortunes MySQL entry is 44th place

---

## What's this talk about?

* Multiplexing is an experimental perf feature released in November 2020 (Npgsql 5.0).
* Other database drivers do this, but not in the .NET world.
* Connection pooling, network buffering, coalescing, and a whole lot of low-level perf goodness.

---

# Let's begin!

---

# Traditional connection pooling

---

## Typical low-level DB code

```csharp
await using var connection = new NpgsqlConnection("...");
await connection.OpenAync();
await using var command = new NpgsqlCommand("SELECT * FROM foo", connection);
await using var reader = await command.ExecuteReaderAsync();

// Consume results from the reader
```

---

## Connection pooling

* Opening a physical connection every time is slow.
  * Network roundtrip(s) (TLS!)
  * In PG, spawn process for each connection
* Like every perf problem in the universe, the answer is caching, or connection pooling

---

## Connection pooling flow

![Traditional connection sequence diagram](diagrams/traditional-sequence-diagram.svg)

---

## Where to pool?

* #1: In .NET: in-process pooling, in the driver.
* #2: Java: the pool is a separate standard API.
* #3: Out-of-process (pgbouncer2, pgpool, odyssey).
* In-process is faster (zero network overhead) and easier to set up.
* External allows pooling across multiple app instances.

![Why not both](img/why-not-both.jpeg)

Note:

* The connection pool is the one component dealing with concurrency and shared mutable state.
* I used to think the Java pooling API model was great, but we'll see that it has drawbacks.

---

## Maximum connections

* The pool always as a max connection size, setting an upper bound on server resources.
* An attempt open when saturated waits until someone else releases (or until timeout).

![Open with wait](diagrams/open-wait.svg)

Note:

* Max Pool Size is 100 by default
* Very important to have a hard limit (server resources). Compare with memory object pooling.
---

# Let's evolve this!

---

## Empty trains

* Physical connections are exclusively "locked" for the duration of the command.
* We're sending out trains with only a single passenger each.

![Empty train](img/empty-train.png)

---

## Fill trains with passengers

* We can fill the same train with multiple unrelated passengers ...
  * .. as long as they arrive around the same time.
* Benefits:
  * Less TCP packet fragmentation
  * Less I/O system calls (both client and server)

---

## Without multiplexing

![Pool without multiplexing](diagrams/pool-without-multiplexing.svg)

---

## With Multiplexing

---

## Busy trains

* The more commands we pack into the same write, the more we save on overhead.
  * In TechEmpower Fortunes, we see around 23 commands per write.
* For this to work, lots of commands need to be submitted simultaneously
  * Optimizes the massive load scenario

---

## Coalescing and Nagling

* This is a form of implicit batching, or *coalescing*.
* Nagle's algorithm: TCP/IP optimization to coalesce together small writes into a single packet.
* Nagling works on a single TCP socket; we combine from multiple query producers.
* Nagling compensates for poor application I/O practices (no buffering).
  * Typically disabled (TCP_NODELAY), because increases latency.

---

# Advantage #1:

## Coalescing

---

## Perf benefits

<ul>
  <li>Without multiplexing, the optimal RPS in TechEmpower Fortunes is <span style="color: red">213,689</span>.</li>
  <li class="fragment">With multiplexing: <span style="color: red">454,254</span> (112% improvement).</li>
  <li class="fragment">... but it's not just about the coalescing :)</li>
</ul>

---

## Saturation

* Remember: in traditional pooling, we wait when saturated - all connections are locked.
* In multiplexing, we can do better: continue pushing commands to the database, even if they're busy!
* We call this "overcapacity mode".

---

## Under capacity

Use only idle connection as long as we can...

![Under capacity](diagrams/multiplexing-under-capacity.svg)

---

## Over capacity

... but keep pushing commands into busy connections

![Over capacity](diagrams/multiplexing-over-capacity.svg)

---

## Advantages

* Pipelining: get commands to the DB faster, even while it's still processing previous commands.
* As long as the DB is processing faster than we send, we're pipelining efficiently.
* If we send faster than the DB processes, eventually TCP buffers get full (TCP zero window).
  * And we block, just like before.

Note:

If we get to TCP zero window, all bets are off - the DB is totally overloaded.

---

# Advantage #2:

## Better handling of saturation

---

## How many DB connections should I have?

* The answer depends on server resources, especially number of cores.
* Also: are queries going to be doing lots of I/O?
* If we increase (in-use) connections too much, we start to cause useless context-switching.

Note:
* Make it clear that TechEmpower Fortunes does very little I/O.

---

## Less connections

* Thanks to multiplexing over-capacity, we can lower the connection count and not starve client-side.
* Do more with less: far more efficient use of physical connections.
* This helps the DB by reducing context switching.
* Even at extremely low connection counts, we're still very efficient.
* The multiplexing pool acts as a sort of "backpressure" for connections.

---

## Multiplexing benefits

1. Coalescing (less overhead)
2. Over-capacity mode (saturation)
3. Reduce number of connections needed

Showdown!

Non-multiplexing

Multiplexing

# We've talked about the good...

## ... now let's talk about the bad.

---

## Statelessness

* Cannot do anything that involves connection state...
* ... especially transactions.
* Can still exclusively rent out connections, as before.

Notes:

* Other examples: temp tables, session variables...

---

## Head of line blocking

* We get query results from the DB in the same order we sent them, FIFO.
* Processing the results of a later query can only happen when earlier results were processing.
* A slow query (or client-side processing!) can block other, unrelated producers.

Note:

* Resultset buffering: but memory.

---

## Some conclusions

* Don't over-parallelize!
* Stop thinking about connections! We just have database command producers.
* Multiplexing relies on an in-process (and probably in-driver) pool.
* Remember: the perf numbers we've seen are TechEmpower benchmarks, massive concurrent load.
* This is all still a bit experimental!

Notes:

* The in-process comment: .NET is (inadvertently) in a good place

---

## The Npgsql team

A special thanks to <span style="color: red" >Nikita Kazmin</span> and <span style="color: red">Nino Floris</span> for their considerable work on multiplexing, and also to Brar Piening!

---

Thank you!

**Shay Rojansky**

<http://roji.org>, @shayrojansky
